5-axis mill-turn universal machining centre with gear machining capability
HSK-A100 14,500 rpm
316 Tool Positions
Power skiving tools
C-axis turning max 500rpm
Working Surface: Pallet: 800mm x 800mm
Loading Capacity: 1000kg
Traverse: (x) 1,000mm (y) 1,100mm (z) 1,175mm
Max tool length 650mm – full use of max tool length at max part size due to tunnel concept
10 Pallet Fastems Flexible Pallet Magazine
HSK-A63 Tooling 20,000 rpm
320 Tool Positions
C-axis turning max 300 rpm
Working Surface: Pallet: 630mm x 630mm
Loading Capacity: 700kg
Traverse: (x) 1,200mm (y) 920mm (z) 610mm
114 Pallet A.P.C
HSK-A63 Tooling 20,000 rpm
320 Tool Positions
C-axis turning max 3000rpm (2 off)
Working Surface: 300mm diameter
Loading Capacity: 80kg Traverse: (x) 500mm (y) 350mm (z) 510mm
Twin-spindle Turning centre with five axis simultaneous milling and gear machining capabilities
Big Bore Main Spindle 3000rpm (1500rpm max power skiving)
Sub-Spindle 3800rpm (2500rpm max power skiving)
Capto C6 B-Axis Turret 12000rpm
80 Tool Positions
Renishaw NC4 & RMP60 units for tooling check and component probing
Gear Machining Package incl. Hobbing and Power Skiving
Lower Turret – 12 Tool Positions
Twin-spindle Turning centre with five axis milling capability
Spindle 6,000 rpm
Sub-spindle
Parts Catcher
Capto C5 Tool Spindle 12,000 rpm
76 Tool Positions
Capto C4 Tool Turret 6,000 rpm
10 Tool Positions
65mm max bar with 1m magazine barfeed
Max turned length 424mm
44 Pallet Fastems Flexible Pallet Magazine
BT40 Tooling 14,000 rpm
240 Tool Positions
Working Surface: Twin Pallets: 500mm x 500mm
Traverse: (x) 730mm (y) 730mm (z) 850mm
BT40 Tooling 12,000 rpm
60 Tool Positions
Working Surface: Twin Pallets: 400mm x 400mm
Load per Pallet: 300 kg
Traverse: (x) 560mm (y) 510mm (z) 510mm
BT40 Tooling 10,000 rpm
30 Tool Positions
Working Surface: 1359mm x 600mm
Loading Capacity: 1000kg
Traverse: (x) 1050mm (y) 530mm (z) 510mm
BT40 Tooling 10,000 rpm
30 Tool Positions
Working Surface: 1100mm x 600mm
Loading Capacity: 800kg
Traverse: (x) 800mm (y) 530mm (z) 510mm
Spindle 5,000 rpm
12 Tool Positions
45mm max bar with 1m magazine barfeed
Max turned length 519mm
Max turned diameter 430mm (170mm standard)
Maximum Tool Length 750mm
Maximum Tool Diameter 420mm
Cutting edge and centre height inspection
LASSO function for inspection of form tools
Accuracy up to 0.002mm
Adaptors for each machine specific tool holder
F4503 Advance
X Axis 500mm / Y Axis 500mm / Z Axis 150mm
Work load 10kg
Oven Capacity 210 litre
Temp up to 200°C
Fully programmable controllers can store up to 9 programs of 18 steps
Multiple ramp/soak cycles possible at different temperatures
Oven Capacity 230 litre
Temp up to 300°C
Fully programmable controllers can store up to 9 programs of 18 steps
Multiple ramp/soak cycles possible at different temperatures
Capable of measuring spur gears up to Ø350mm and bevel gears up to Ø200mm.
Fixed Head
Measuring volume 500 x 400 x 300mm
Volumetric Length Measuring Error 0.7 + L/400 µm
Quindos Gear Software with Straight Bevel Gear module
Maximum permitted table load 250kg
Working Surface: 800mm x 1500mm
Traverse: (x) 700mm (y) 1000mm (z) 450mm
Working Surface: 500mm x 700mm x 400mm
Traverse: (x) 500mm. (y) 700mm. (z) 400mm
Probe Head PH8 – Probes TP2
| Measuring ranges 400 to 1800 mm 2D programming for serial measurement |
Optical measurement of components and tooling
Digital readout
Digitally linked visual inspection for components and tooling with high magnification
Easy to use visual inspection with low magnification for component inspection
Fast and clear marking on and processing of resins and metals
Full-Field Auto-Focus
Autofocus Anywhere
Built-In Vision
Data-Driven Analytics
